10.1 Inch 4G AI Monitor DVR for Fleet Safety and Remote Monitoring
Product Overview
This 10.1 inch monitor DVR is more than just a display screen. It combines monitoring, recording, connectivity and AI warning functions into one integrated solution for commercial vehicles.
Compared with a standard vehicle monitor, it can help users:
- view multiple camera channels in real time
- record video locally
- access live video remotely through 4G
- improve driving safety with AI warnings
- monitor parked vehicles
- support anti-fuel theft and security applications
AI Functions
ADAS
- Lane departure warning
- Do not cross lane line warning
- Pedestrian warning
- Front vehicle start reminder
- Forward collision warning
BSD
- Blind-spot detection
- Warning for people
- Warning for vehicles
- Warning for objects
DMS
- Camera blocked warning
- Phone call warning
- Smoking warning
- Fatigue driving warning
- Distracted driving warning
- Seat belt unfastened warning
- Driver not detected warning
4G Remote Monitoring Functions
This model supports practical 4G functions for fleet management, including:
- live video
- route playback
- intercom
- video playback
- remote fuel theft alarm
It is suitable for projects that require both local recording and remote vehicle monitoring.
Parking Monitoring and Anti-Fuel Theft
The monitor supports time-lapse parking recording for:
- 8 hours
- 12 hours
- 24 hours
- 48 hours
It can also be used in anti-fuel theft or anti-theft applications with dedicated cameras and remote APP alarm notification.
Other Supported Functions
- Navigation and positioning
- Wireless screen mirroring for Android / iOS / HarmonyOS phones
- Bluetooth hands-free calling
- Bluetooth music playback
- FM audio transmitter
- Dual-band Wi-Fi: 2.4G / 5G
- USB port
- Built-in speaker
- Multi-language menu
Applications
This 10.1 inch 4G AI monitor DVR is suitable for:
- buses
- trucks
- vans
- fuel trucks
- construction vehicles
- agricultural machinery
- mining vehicles
- fleet management vehicles
Technical Specifications
Screen Size: 10.1 inch
Video System: PAL / NTSC
Resolution: 1024 (H) × 600 (V)
Brightness: 500 cd/m²
Contrast Ratio: 800:1
Viewing Angle: 85/85/85/85
Video Input: 4CH / 6CH CVBS; AHD 720P / 1080P
Audio Output: Built-in speaker
Memory: 4 Gbit DDR3
External Storage: Up to 128GB SD card
Recording File Format: TS
Video Compression: H.264
Operation: Touch screen
Power Input: DC 12V–36V
Operating Temperature: -20°C to +70°C
Storage Temperature: -30°C to +80°C
Installation: Bracket mount / desktop mount
Cable Connector: Aviation connector
Housing Material: ABS plastic
Dimensions: 249 × 168 × 30 mm
FAQ
Q1: Is this product only a monitor?
No. It combines monitor, DVR, 4G remote monitoring and AI warning functions in one device.
Q2: What camera types does it support?
It supports 4CH / 6CH CVBS and AHD 720P / 1080P input.
Q3: Does it support remote monitoring?
Yes. It supports live video, playback, intercom and remote alarm through 4G.
Q4: What vehicles is it suitable for?
It is suitable for buses, trucks, vans, fuel trucks, construction vehicles and other commercial vehicles.
