Product Overview
The 360° Surround View Active Safety Driving Assistant System is designed for commercial vehicles that need wider visibility around the vehicle body and active safety alerts in blind areas. It combines ultra-wide-angle vehicle cameras, panoramic image stitching, AI-based pedestrian and vehicle recognition, and audio-visual warnings to help drivers monitor surrounding risks during turning, reversing, parking and low-speed operation.
This system is suitable for trucks, buses, engineering vehicles, municipal vehicles, logistics vehicles and other commercial vehicles where blind spot monitoring and surrounding awareness are important for daily operation.
Quick Answer
A 360° surround view active safety system uses multiple cameras around the vehicle to create a bird’s-eye view image. Combined with AI detection, it can identify pedestrians or vehicles entering preset warning zones and provide visual and voice alerts to support safer driving decisions.
Main Safety Monitoring Functions
- 360° panoramic bird’s-eye view image generated from multiple ultra-wide-angle cameras.
- AI vision algorithm for pedestrian and vehicle recognition around blind areas.
- Audio-visual alerts when a target enters a preset dangerous zone.
- Turn signal, reversing and blind spot warning support for daily driving scenarios.
- Four-channel camera mode for commercial vehicle surround monitoring.
- Supports 1080P / AHD camera input depending on system configuration.
Recommended Applications
Truck Blind Area Monitoring
For large trucks, the system helps monitor areas around the vehicle that are difficult for the driver to see directly, especially during turning, reversing and low-speed maneuvering.
Engineering and Construction Vehicles
For vehicles working around pedestrians, machines and obstacles, the 360° view and warning function can support better awareness in complex work sites.
Bus and Municipal Vehicle Safety
For buses, sanitation vehicles and city service vehicles, the system can help drivers monitor surrounding pedestrians, cyclists and roadside obstacles.
Technical Specification Reference
| Item | Specification |
|---|---|
| System Type | 360° surround view active safety driving assistant system |
| Video Input | Supports 1080P / AHD camera input depending on configuration |
| Camera Mode | Four-channel camera mode |
| Video Output | CVBS x1, HDMI x1, VGA x1, AHD optional |
| Video Compression | H.265 |
| Storage | SD 8-256GB; optional mini PCIe SSD 128GB-2TB |
| Operating Voltage | DC 10-36V |
| Operating Temperature | -20°C to +70°C |
| Storage Temperature | -40°C to +80°C |
| Protection Level | IP51 |
| Product Size | 100 x 130 x 29 mm |
| Weight | Approx. 0.4 kg |
How to Choose a 360° Surround View Safety System
When selecting a 360° surround view system, buyers should confirm the vehicle size, camera mounting positions, display output requirement, recording storage capacity, operating voltage and whether AI warning functions are required. For fleet projects, it is also useful to confirm whether the system needs to work with existing monitors, MDVR equipment or platform-based fleet management systems.
Related Xinvisual Products and Solutions
- 360° Surround View Systems
- AI Cameras
- MDVR Systems
- AI Blind Spot Detection Solution
- Request a System Recommendation
Related Technical Resources
- AI Blind Spot Detection Camera Solution for commercial vehicle side and rear risk monitoring.
- Fleet Camera Monitoring Solution for MDVR, cameras and monitor integration in fleet projects.
- DVS / BSIS / MOIS Camera System Guide for understanding European and UK vehicle safety camera application requirements.
FAQ
What vehicles can use this 360° surround view system?
It can be configured for trucks, buses, engineering vehicles, municipal vehicles, logistics vehicles and other commercial vehicle projects.
Does the system provide AI warning alerts?
Yes. According to the source specification, the system uses an AI vision algorithm to recognize pedestrians and vehicles and provide warnings when targets enter preset risk zones.
Can it support video recording?
The system supports H.265 video compression and storage by SD card, with optional mini PCIe SSD storage depending on configuration.
Request a 360° Surround View Safety System Recommendation
Tell us your vehicle type, camera quantity, display output, recording requirement and installation scenario. Xinvisual can recommend a suitable 360° surround view active safety configuration for your project.
