10.1 Inch Ultra-thin Dropdown Monitor with DVD Player
The Xinvisual 10.1 inch ultra-thin dropdown monitor is designed for passenger entertainment and vehicle display projects in buses, coaches, RVs, shuttle vehicles and vans. It combines a compact roof-mounted structure with DVD playback, USB / SD media support, HDMI input and AV input options.
For buyers who need a simple, space-saving display instead of a larger Android roof-mounted monitor, this model is suitable for vehicle interiors where installation space, folding design and reliable media playback are important.
Key Features
- 10.1 inch digital screen for compact passenger entertainment and roof-mounted display applications.
- Ultra-thin housing with approximately 3.2 cm profile for cleaner vehicle interior installation.
- Built-in DVD player for direct video playback in selected vehicle entertainment projects.
- USB, SD, HDMI and AV input options for flexible media source connection.
- Fold-down roof-mounted design for buses, vans, RVs and shuttle vehicles.
- Optional housing colors including black, beige and gray to match different interior styles.
- DC 12V / 24V vehicle power support for common commercial vehicle electrical systems.
Recommended Vehicle Applications
Buses and Coaches
The 10.1 inch dropdown monitor can be installed in passenger areas to provide video playback for route information, entertainment or onboard media content.
RVs and Motorhomes
For RV and motorhome projects, the fold-down structure helps save interior space while keeping multimedia functions available for passengers.
Shuttle Vehicles and Vans
The compact size is suitable for small passenger transport vehicles where a larger roof-mounted monitor may be unnecessary or difficult to install.
Commercial Passenger Vehicles
For fleet operators and vehicle builders, this model can be used as a practical roof-mounted display for passenger information and entertainment systems.
Technical Specifications
| Screen size | 10.1 inch digital screen |
| Resolution | 1366RGB(H) x 768(V) |
| Brightness | 300 cd/m2 |
| Contrast | 300:1 |
| Dimensions | 286 x 263 x 35 mm |
| Ultra-thin housing | Approx. 3.2 cm |
| Screen adjustment | Right 90 degrees, left 180 degrees |
| Inputs | USB, SD, HDMI, AV input options |
| Audio | Built-in dual-channel IR / FM / speaker for selected MP5 / DVD configurations |
| Power | DC 12V / 24V vehicle power systems |
| Housing colors | Black / beige / gray optional |
Available Configurations
Monitor Version
Suitable for basic display applications with two-way video inputs and one-way trigger wires.
MP5 Version
Supports USB, SD, HDMI and AV input playback for customers who need flexible media source options.
DVD Version
Designed for projects that still require direct DVD playback together with USB / SD and AV input support.
Buyer Checklist
- Confirm whether your project requires monitor-only, MP5 or DVD configuration.
- Check available roof installation space before selecting a screen size.
- Confirm vehicle voltage and wiring requirements.
- Choose housing color based on the vehicle interior.
- Confirm whether HDMI input, AV input or USB / SD playback is required.
- For fleet or OEM projects, confirm logo, packaging and connector customization needs before production.
Compare with 15.6 Inch Android Roof Mounted Monitor
If your project needs a larger screen, Android functions, smartphone mirroring or a more advanced passenger display experience, the 15.6 inch Android roof mounted monitor may be a better option.
If your project needs a compact fold-down monitor with DVD or basic media playback, this 10.1 inch ultra-thin dropdown monitor is a practical choice.
Related Roof-mounted Monitor Products
Explore more vehicle display options in our Roof-mounted Monitors product category.
FAQ
What vehicles is this 10.1 inch dropdown monitor suitable for?
It is suitable for buses, coaches, RVs, shuttle vehicles, vans and other passenger transport applications that need a compact roof-mounted display.
Does this monitor support DVD playback?
Yes. A DVD version is available for projects that require direct DVD playback. MP5 and monitor-only configurations can also be selected based on project needs.
Can the housing color be customized?
Black, beige and gray housing colors are available. For OEM projects, please contact Xinvisual to confirm customization details.
Can this product be used for OEM or fleet projects?
Yes. Xinvisual supports OEM and bulk order projects, including configuration selection, connector requirements, packaging and engineering support.
Request a Quote for Your Vehicle Display Project
Tell us your vehicle type, target application, screen size requirement and preferred configuration. Our team can recommend a suitable roof-mounted monitor solution for your project.
