Product parameters:
| XST-DMS-31 | ||
| Sensor Chip Parameters | Chip Model | JX-H66 |
| Sensitive area size | 1/3 inch | |
| Pixel | 2 million | |
| Effective resolution | 1292H*968V (960p) | |
| Frame rate | 25 fps | |
| Wide Dynamic | Not supported | |
| Lens parameters-1（DM-DH31-L4 ） | EFL | 4.0mm |
| Viewing Angle（FOV） | H: 72°， V：53 | |
| Aperture | 2.5 | |
| Lens | All-glass | |
| Filter centre wavelength | 940nm IR | |
| Lens parameters-2（DM-DH31-L6 ） | EFL | 6.0mm |
| Viewing Angle（FOV） | H: 53°， V：34° | |
| Lens | All-glass | |
| Filter centre wavelength | 940nm | |
| Optical parameters | Infrared lamp centre wavelength | 940nm |
| Fill light mode | Day and night constant light | |
| Electrical parameters | Video Output | Analogue HD AHD 720P |
| Power supply | DC 12V (9~18V) | |
| Operating current | 130mA @ 12V | |
| Other parameters | Cable length | 1.5m, M12 aviation head (female) |
| Built-in speaker | None | |
| Working Environment | -20~70℃，45%< R.H.<80% | |
| Storage environment | -30~80℃，30%< R.H.<90% | |
| Dimensions | 102*73*37 mm | |
| Weight (with cable) | 212g | |
| Fixing method | Self-tapping screws | |
Product Overview
This driver fatigue monitoring camera is designed for commercial vehicle DSM applications where fleet operators need better awareness of driver status and driving risk. It can be used on trucks, buses, coaches, logistics vehicles and fleet retrofit projects as part of a wider vehicle safety monitoring system.
The camera monitors the driver area and can support driver status detection applications such as fatigue, distraction or abnormal driving behavior monitoring, depending on the connected system configuration and software platform.
Typical Applications
Truck and Logistics Fleets
For long-distance transport, delivery vehicles and logistics fleets, a DSM camera can help fleet teams monitor driver status together with road-facing cameras, side cameras and MDVR recording systems.
Bus and Coach Operations
For passenger transport, shuttle buses and coaches, driver monitoring can support safer daily operation by helping detect drowsiness or inattention during routes and long-distance driving.
Fleet Retrofit and OEM Projects
The camera can be integrated with monitors, MDVR systems or customized vehicle safety platforms depending on the installation space, power supply, connector type and fleet management requirements.
Recommended System Combination
For video recording and fleet review applications, this DSM camera can be combined with the 1080P 4G Hard Disk MDVR System.
Vehicles that also need exterior blind spot monitoring can compare the BSD AI Camera or review the AI Blind Spot Detection Camera Solution.
For rear-view visibility, the AHD Reversing Camera with IR Night Vision can be used as a complementary camera option.
For complete project planning, visit the Fleet Camera Monitoring Solution page to see how cameras, monitors and MDVR systems can be combined for commercial vehicles.
FAQ
What is a driver fatigue monitoring camera used for?
A driver fatigue monitoring camera is used in commercial vehicle DSM systems to support driver status monitoring, including fatigue, distraction or abnormal driving behavior detection applications.
Can this DSM camera work with an MDVR system?
Yes. Depending on the system configuration, the camera can be integrated with an MDVR system for video recording, fleet review and vehicle safety monitoring applications.
Which vehicles can use this driver monitoring camera?
It can be used for trucks, buses, coaches, logistics vehicles and fleet retrofit projects where driver status monitoring is required.
Can Xinvisual support OEM or customized DSM projects?
Xinvisual can support OEM/ODM vehicle camera and monitoring projects, including system matching, connector selection and installation-related configuration discussions.
