Product Overview
The 1080P AHD Mini Vehicle Camera is a compact camera designed for commercial vehicle monitoring, reversing view, side view and space-limited installation positions. With a GC2053 image sensor and 1920 x 1080 AHD output, it provides clear video for vehicle monitors and MDVR systems.
Its small housing makes it suitable for trucks, buses, forklifts, trailers, vans and OEM vehicle camera projects where a discreet camera position is required. The IP67 waterproof housing supports outdoor vehicle use in rain, dust and daily road conditions.
Key Features
- 1080P AHD video: 1920(H) x 1080(V) resolution for clearer vehicle monitoring.
- GC2053 image sensor: 1/2.9 inch sensor for stable image output.
- 120 degree wide angle: Supports wider rear, side or blind area viewing.
- IP67 waterproof housing: Suitable for outdoor commercial vehicle installation.
- Compact mini design: Fits limited installation spaces on vehicle bodies, panels or special equipment.
- DC12V power: Designed for common vehicle camera system applications.
- AV output: Can be matched with compatible vehicle monitors or MDVR systems.
Technical Specifications
| Item | Specification |
| Image sensor | 1/2.9 inch GC2053 |
| Video system | PAL / NTSC |
| Resolution | 1920(H) x 1080(V) AHD |
| Viewing angle | 120 degree |
| Focal length | F=2.8mm |
| Image display | Normal image, no guide line |
| Waterproof rating | IP67 |
| Power supply | DC12V |
| Operating temperature | -20°C to +70°C |
| Output | DC + AV plug |
Recommended Applications
Truck and Van Monitoring
Installed at rear, side or auxiliary viewing positions, the mini camera can support reversing, lane-side viewing and driver awareness in commercial vehicle applications.
Bus and Passenger Transport
The compact camera can be used with vehicle monitors for rear view, side view or interior monitoring positions depending on the vehicle design and wiring plan.
Forklifts and Industrial Vehicles
For forklifts, warehouse vehicles and industrial equipment, the camera can support rear view or auxiliary view applications when matched with a suitable monitor.
OEM Vehicle Camera Projects
The mini housing is useful for OEM projects where camera size, installation position, cable length and connector type need to be confirmed during engineering evaluation.
Recommended System Combination
This 1080P AHD mini camera is commonly used as part of a complete vehicle camera system. Buyers can match it with a compatible vehicle monitor, AHD MDVR system or custom OEM wiring solution.
| Use Case | Recommended Combination |
| Basic rear view | Mini AHD camera + vehicle monitor |
| Fleet recording | Mini AHD camera + AHD MDVR system |
| Forklift auxiliary view | Mini AHD camera + compact monitor |
| OEM integration | Mini AHD camera + customized cable / connector solution |
Buyer Checklist
- Confirm the installation position and viewing direction.
- Confirm whether the system requires PAL or NTSC.
- Confirm monitor or MDVR compatibility before ordering.
- Confirm cable length and connector requirements for OEM projects.
- Confirm whether guide lines are required, because this model is listed as normal image without guide line.
Related Xinvisual Solutions
- Vehicle Cameras
- Vehicle Monitors
- Fleet Camera Monitoring Solution
- Forklift Safety Camera Solution
- Contact Xinvisual for OEM camera recommendations
FAQ
Is this camera suitable for commercial vehicles?
Yes. It can be used for trucks, buses, vans, forklifts, trailers and other commercial vehicle camera monitoring applications when matched with a compatible monitor or MDVR.
Can this mini camera be used with an MDVR system?
Yes. It can be used with compatible AHD MDVR systems for fleet video recording. Buyers should confirm input format, connector and cable length before installation.
Is the camera waterproof?
The model is listed with an IP67 waterproof rating, which supports outdoor vehicle installation in common rain, dust and road conditions.
Does this camera include guide lines?
The listed image display is normal image without guide line. If guide lines are required for a project, please confirm the requirement before ordering.
Can Xinvisual support OEM customization?
Yes. Xinvisual can support OEM/ODM discussions for camera configuration, cable length, connector type and system matching based on project requirements.
